ZIMO DCC

ZIMO LSFRWS5R VISATON Speaker - 50mm Round 8 ohm 4 watt - Compact Frameless

(No reviews yet) Write a Review
UPC:
9009606774255
MPN:
LSFRWS5R
Condition:
New
MSRP: $21.36
Price: $18.79
— You save $2.57

Description

ZIMO LSFRWS5R VISATON Speaker - 50mm Round 8 ohm 4 watt - Compact Frameless


This is a broad range speaker perfect for use with ZIMO large scale sound decoders (MX697, MX699, .... 10V / 6W - amplifier).

It can also be used with ZIMO small scale sound decoders (MX644, MX645, .... 5V / 3W - amplifier), however, the low power output of the amplifier is not optimized for the capability the speaker.


Specifications:
  • 50mm Round - 21mm Tall
  • 8 ohm
  • 4 Watts
  • 150Hz-20kHz F.R.R.

All ZIMO decoders are able to use 8 ohm speakers, most can use 4 ohm speakers or (2) 8 ohm speakers connected in parallel.

Miniature types such as MX648, MX649 and MX658 should only use 8 ohm speakers.

Small scale sound decoders (MX645, MX644, MX646, MX648, ...) work with 5 V power supply for the sound amplifier (miniature types create 1W audio power, otherwise 3W audio power).  Typical N- and 00/H0 speakers which are 0.5 W to 2 W.

Large scale sound decoders (MX695, '696,' 697, '699) work with 10 V power supply (and 10 W audio power into 4 ohms).  Therefore ZIMO large scale decoders (10 V) should ONLY use Speakers > 3W.

ZIMO offers special types of miniature rectangular speakers with special resonance bodies and are produced in cooperation with ZIMO business partners.  They offer excellent sound quality considering the size.  These special models are not commercially available elsewhere.

The other listed speakers (Round Speakers and VISATON speakers) are standard types.





View AllClose

Additional Resources

MANUFACTURERS WEBSITE:
SOUND CONFIGURATION & SOUND FILE RESOURCES:
FIRMWARE & SOFTWARE RESOURCES:
PRODUCT MANUALS & TECHNICAL DOCUMENT RESOURCES:
MANUFACTURERS WARRANTY & REPAIRS:
ADDITIONAL INFORMATION - DCC TIPS:
ADDITIONAL INFORMATION (1):
NA
ADDITIONAL INFORMATION (2):
View AllClose

Additional Information

PRODUCT CLASS:
Large Scale (S*-O-G)
SPEAKER TYPE:
Traditional - High Bass
SPEAKER INTERFACE:
Hardwire - Solder Pad
SIZE-INCH (Dia x H):
D1.97 x 0.98 in
SIZE-METRIC (Dia x H):
D50 x 25 mm
NUMBER OF SPEAKERS:
1
MAX POWER:
10 W
FREQ RESPONSE RANGE:
150 Hz - 20 kHz
IMPEDANCE:
8 Ohms
SOUND LEVEL (W/O CHAMBER):
0 db
ENCLOSURE INCLUDED:
No
ASSEMBLY REQUIRED:
NA
ADDITIONAL FEATURES:
NA
NOTES (1):
NA
NOTES (2):
NA
